Description
FHCT is the safest, economical and easiest-to-install way to warm floors and provide years of lasting comfort.
Features
- Single point connection, easy to install
- Twin conductor cable with screen, no measurable electromagnetic fields
- Various sizes of floor heating cables are designed to fit the heated area of any floor
- Compatibility with all standard subflooring materials
- Safety approved for outdoor and wet locations
- Durable construction, long life
- 25-year limited warranty against manufacturing defects for floor warming, 2-year limited warranty against manufacturing defects for other usage
Cable specifications
| Cable Construction | Twin conductor |
| Operating voltage | 230V |
| Power output | 12W/m, 16W/m, 18W/m, 20W/m |
| Cable diameter | 3.6mm |
| Min. bending radius | 25mm |
| Conductor insulation | Fluoropolymer |
| Outer insulation | PVC |
| Max. ambient temperature | 30℃ |
| Min. installation temperature | 5℃ |
| Cold lead | 2.5m length |
Thermostat specifications
| Functions | On/Off control, digital display, 7-day programmable |
| Supply Voltage | 230V, 50/60 Hz |
| Max. switching current | 16 Amp |
| Temperature control range | 5 to 40°C |
| Ambient range | 0 to 40°C |
| Floor temperature sensor | 2-wire, 3.0m lead wire |
